2003 Mercedes-Benz C230 Kompressor Wheels & Rims
2003 Mercedes-Benz C230 Kompressor Wheel Gallery — See It On Your Car
Real Mercedes-Benz C230 builds and AI-rendered fitment previews. Visualize any wheel on your C230 with our free wheel visualizer before you buy.
Shop Wheels for 2003 Mercedes-Benz C230 Kompressor
Showing 8 of 8+ wheels compatible with the 2003 Mercedes-Benz C230
Your 2003 Mercedes-Benz C230 Kompressor Kompressor rolls on a 5x112 bolt pattern with staggered sizing—16x7 upfront and 16x8 out back. ThreePiece.us stocks premium wheels from Heritage Wheel, Aodhan, Motegi Racing, Work Wheels, Niche 1PC, Petrol, Rotiform 1PC, and MRR, all verified to bolt on perfectly. Every wheel ships free to the lower 48 states.
Looking to upgrade your C230's appearance? We offer compatible sizes ranging from 15-inch to 17-inch diameters, giving you flexibility in your build. Each wheel is tested for fitment on your exact vehicle before it ships, ensuring a hassle-free installation every time.
2003 Mercedes-Benz C230 Kompressor Wheel Fitment Guide — What Works & What to Avoid
Your 2003 Mercedes-Benz C230 Kompressor rolls on a 5x112 bolt pattern with 16-inch wheels as stock—7 inches wide up front with a 31mm offset, and 8 inches wide in back at 32mm offset. Sizes from 15 to 17 inches work here, ranging from 15x6 all the way to 17x8.5, so you can stay staggered or go square depending on your look.
The 5x112 bolt pattern is non-negotiable; nothing else bolts on safely. Make sure any wheel you choose has a center bore of at least 66.6mm, or use hub-centric rings to avoid vibration and runout. Aggressive offsets or widths beyond what's listed risk contact with your fenders and suspension, so stick within the verified sizes to keep everything tucked and trouble-free.
Every wheel in our catalog for your C230 is guaranteed to bolt on and ships free to the lower 48 states. We stock Heritage Wheel, Aodhan, Motegi Racing, Work Wheels, Niche 1PC, Petrol, Rotiform 1PC, and MRR—all ready to fit your Kompressor.
2003 Mercedes-Benz C230 Kompressor Wheel Fitment Specifications
The 5x112 bolt pattern determines which wheels physically bolt onto your car, while the 66.6mm center bore ensures a hub-centric fit. This car runs a factory staggered setup: 16x7 +31 front and 16x8 +32 rear.
Lug Type
bolt
Thread Size
M12x1.5
Torque Spec
85 ft-lbs
TPMS
No
2003 Mercedes-Benz C230 Kompressor Compatible Wheel Sizes — Front Axle
| Wheel Size | Offset Range | Compatible Tires | Notes |
|---|---|---|---|
| 15x6 | +33 to +57 | 195/65R15, 215/60R15, 225/55R15 | — |
| 15x6.5 | +33 to +53 | 195/65R15, 235/55R15, 215/60R15 | — |
| 15x7 | +33 to +47 | 195/65R15, 235/55R15, 215/60R15 | — |
| 16x7 | +31 to +47 | 205/55R16, 225/50R16, 195/60R16 | — |
| 17x7 | +33 to +42 | 225/45R17, 215/45R17, 225/50R17 | — |
| 16x7.5 | +33 to +42 | 205/55R16, 225/50R16, 215/55R16 | — |
| 17x7.5 | +33 to +42 | 215/45R17, 225/45R17, 225/50R17 | — |
| 18x7.5 | +33 to +38 | 225/40R18 | — |
| 16x8 | +33 to +38 | 225/50R16 | — |
| 17x8 | +30 to +38 | 225/45R17, 215/45R17, 225/50R17 | — |
| 18x8 | +33 to +38 | 225/40R18 | — |
| 19x8 | +33 to +38 | 235/35R19 | — |
2003 Mercedes-Benz C230 Kompressor Compatible Wheel Sizes — Rear Axle
| Wheel Size | Offset Range | Compatible Tires | Notes |
|---|---|---|---|
| 19x10 | +25 to +35 | 235/35R19, 255/30R19, 265/30R19 | — |
| 17x7.5 | +33 to +40 | 245/40R17 | — |
| 17x8 | +25 to +38 | 245/40R17 | — |
| 19x8 | +25 to +38 | 225/35R19 | — |
| 17x8.5 | +25 to +38 | 245/40R17 | — |
| 18x8.5 | +25 to +38 | 245/40R18, 255/35R18 | — |
| 19x8.5 | +25 to +38 | 235/35R19, 255/30R19 | — |
| 17x9 | +25 to +38 | 245/40R17, 255/40R17 | — |
| 18x9 | +25 to +38 | 245/40R18, 255/35R18 | — |
| 19x9 | +25 to +38 | 235/35R19, 255/30R19, 265/30R19 | — |
Best Wheel Brands for the Mercedes-Benz C230
- BBS — LM, RS, FI, CI-R
- Volk Racing — TE37, ZE40
- Work Wheels — Meister, Emotion
- TSW — Bathurst, Nurburgring
- Rotiform — FLG, OZR, BUC
- Enkei — RPF1, TS-V
Complete Your 2003 Mercedes-Benz C230 Kompressor Build
- Mercedes-Benz C230 coilovers — pairs well with a wheel upgrade
- Mercedes-Benz C230 exhaust systems — pairs well with a wheel upgrade
- Mercedes-Benz C230 suspension — pairs well with a wheel upgrade
- Mercedes-Benz C230 brakes — pairs well with a wheel upgrade
- Wheel & tire packages — pre-mounted, balanced, shipped ready to bolt on
- Installation accessories — hub rings, extended studs, TPMS kits, spacers
