1980 Gmc C3500 Base Wheels & Rims
Fitment shared across: Base, High Sierra, Sierra Classic, Sierra Grande
Shop Wheels for 1980 Gmc C3500 Base
The 1980 GMC C3500 Base, High Sierra, Sierra Classic, and Sierra Grande all share the same straightforward fitment. Your truck came equipped with 16x7 wheels wearing a 13 offset, mounted on an 8x165.1 bolt pattern. ThreePiece.us stocks premium options from Carolina Forged, Vision, WELD Off-Road, American Truxx, Black Rhino, Fuel 1PC, American Racing, and Tuff that bolt right on.
We verify every wheel's fitment before it ships, so you're guaranteed proper clearance and handling. Your C3500 accepts multiple sizes ranging from 16.5x6 all the way up to 17x9, giving you flexibility in your build. All orders to the lower 48 states qualify for free shipping, making an upgrade to quality wheels the smart move.
1980 Gmc C3500 Base Wheel Fitment Specifications
The 8x165.1 bolt pattern determines which wheels physically bolt onto your truck, while the 117mm center bore ensures a hub-centric fit. The factory equips this truck with 16x7 wheels at a +13 offset.
Lug Type
nut
Thread Size
1/2 UNF
Torque Spec
74 ft-lbs
TPMS
No
1980 Gmc C3500 Base Compatible Wheel Sizes
| Wheel Size | Offset Range | Compatible Tires | Notes |
|---|---|---|---|
| 16x6 | -6 to +25 | 7.50-16 | — |
| 16.5x6 | -6 to +25 | 9.50-16.5, 8.75-16.5 | — |
| 16x6.5 | -6 to +25 | 7.50-16 | — |
| 16x7 | -6 to +25 | 215/85R16, 245/75R16, 225/75R16 | — |
| 16x7 | -6 to +25 | 245/75R16, 265/75R16, 31/10.50R16 | 2. Body Modification Required |
| 16x7.5 | -6 to +25 | 215/85R16, 245/75R16, 225/75R16 | — |
| 16x8 | -6 to +25 | 225/75R16, 245/75R16, 215/85R16 | — |
| 17x8 | -6 to +25 | 265/70R17, 30/10.00R17, 31/10.50R17 | — |
| 16x8.5 | +18 to +25 | 225/75R16, 245/75R16, 215/85R16 | 2. Body Modification Required |
| 17x8.5 | +18 to +25 | 265/70R17, 31/10.50R17, 31/12.50R17 | 2. Body Modification Required |
| 17x9 | +9 to +26 | 265/70R17, 31/10.50R17, 31/12.50R17 | 2. Body Modification Required |
Best Wheel Brands for the Gmc C3500
- Fuel Forged — FF12, FF19, FF41
- Fuel 1PC — Maverick, Assault, Blitz
- Method Race Wheels — MR305, MR701
- American Racing — AR924, VN507
- Heritage Wheel — Bushido, Ebisu
