2002 Volvo V70 Wheels & Rims
2002 Volvo V70 Wheel Gallery — See It On Your Car
Real Volvo V70 builds and AI-rendered fitment previews. Visualize any wheel on your V70 with our free wheel visualizer before you buy.
Shop Wheels for 2002 Volvo V70
Showing 8 of 8+ wheels compatible with the 2002 Volvo V70
The 2002 Volvo V70 in 2.4T, AWD, Base, T5, and X/C trims rolls on a 5x108 bolt pattern with a stock setup of fifteen-inch by six-and-a-half-inch wheels at forty-three millimeters offset. At ThreePiece.us, we stock premium options from Heritage Wheel, Petrol, Asanti Black, fifteen52, Work Wheels, Niche 1PC, Motegi Racing, and Mazzi that bolt right on and ship free to the lower forty-eight states.
Your V70 can accommodate an impressive range of sizes, from fifteen to eighteen inches in diameter, with multiple width options at each size. Every wheel we offer for your vehicle is verified to fit perfectly before it ships, ensuring you get exactly what you need without compatibility guesswork.
2002 Volvo V70 Wheel Fitment Guide — What Works & What to Avoid
The 2002 Volvo V70 across all trims uses a 5x108 bolt pattern with a 65.1mm hub-centric center bore. Your stock setup runs 15x6.5 wheels at 43mm offset. You can step up to 16-inch, 17-inch, or 18-inch sizes while staying square, with widths ranging from 6.5 to 8 inches depending on diameter. Offset and width combinations remain consistent across all trims sharing this fitment.
When shopping wheels for your V70, remember that only the 5x108 bolt pattern will fit—no exceptions across platforms. Since many aftermarket wheels have larger center bores, use hub-centric rings to ensure proper centering and vibration-free performance. Aggressive offset or excessive width can risk rubbing on fender lips and suspension components, so verify your chosen setup's offset and width fall within compatible ranges before ordering.
Every wheel in our V70 collection bolts on cleanly and ships free throughout the lower 48 states. We keep Heritage Wheel, Petrol, Asanti Black, fifteen52, Work Wheels, Niche 1PC, Motegi Racing, and Mazzi in stock so you can upgrade your wagon's look with confidence.
2002 Volvo V70 Wheel Fitment Specifications
The 5x108 bolt pattern determines which wheels physically bolt onto your car, while the 65.1mm center bore ensures a hub-centric fit. The factory equips this car with 15x6.5 wheels at a +43 offset.
Lug Type
bolt
Thread Size
M14x1.5
Torque Spec
93 ft-lbs
TPMS
Yes
2002 Volvo V70 Compatible Wheel Sizes
| Wheel Size | Offset Range | Compatible Tires | Notes |
|---|---|---|---|
| 15x6.5 | +33 to +45 | 195/65R15, 205/65R15, 195/60R15 | — |
| 16x6.5 | +33 to +45 | 205/60R16, 215/55R16, 225/55R16 | — |
| 15x7 | +33 to +45 | 195/65R15, 195/60R15, 215/60R15 | — |
| 16x7 | +33 to +48 | 205/60R16, 215/55R16, 225/55R16 | — |
| 17x7 | +33 to +47 | 225/45R17, 235/45R17 | — |
| 18x7 | +33 to +45 | 215/45R18, 225/45R18 | — |
| 16x7.5 | +35 to +45 | 205/60R16, 215/55R16, 225/50R16 | — |
| 17x7.5 | +35 to +47 | 225/45R17, 235/45R17, 215/50R17 | — |
| 18x7.5 | +35 to +47 | 215/45R18, 225/40R18 | — |
| 19x7.5 | +42 to +46 | 225/45R19, 225/40R19, 225/35R19 | 21. TUV: Check fitment, possible clearance issues: 24. TUV: Check tyre fitment suitability |
| 16x8 | +35 to +43 | 225/55R16, 235/50R16 | — |
| 17x8 | +35 to +45 | 225/45R17, 235/45R17, 225/50R17 | — |
| 18x8 | +35 to +45 | 215/45R18, 225/40R18, 235/40R18 | — |
| 19x8 | +35 to +45 | 235/35R19 | — |
| 20x8 | +40 to +45 | 225/30R20 | 1. Check fitment, possible clearance issues |
| 18x8.5 | +35 to +40 | 245/45R18, 245/35R18, 235/50R18 | 21. TUV: Check fitment, possible clearance issues: 22. TUV: Body Modification Required: 23. TUV: Extreme fitment/check lift kit requirements: 24. TUV: Check tyre fitment suitability |
| 19x8.5 | +30 to +42 | 245/40R19, 235/35R19, 225/35R19 | 21. TUV: Check fitment, possible clearance issues: 22. TUV: Body Modification Required: 23. TUV: Extreme fitment/check lift kit requirements: 24. TUV: Check tyre fitment suitability |
| 20x8.5 | +35 to +35 | 245/35R20, 245/30R20 | 21. TUV: Check fitment, possible clearance issues: 22. TUV: Body Modification Required: 24. TUV: Check tyre fitment suitability |
