2022 Toyota GR86 Wheels & Rims
2022 Toyota GR86 Wheel Gallery — See It On Your Car
Real Toyota GR86 builds and AI-rendered fitment previews. Visualize any wheel on your GR86 with our free wheel visualizer before you buy.
Shop Wheels for 2022 Toyota GR86
Showing 8 of 8+ wheels compatible with the 2022 Toyota GR86
The 2022 Toyota GR86 Base and Premium trims roll on 18x7.5 wheels with a 45mm offset, secured by a 5x100 bolt pattern. At ThreePiece.us, we stock premium wheels from trusted brands like Work Wheels, Enkei, and Motegi Racing that fit your GR86 perfectly. Every wheel is verified to bolt on, and we ship free to the lower 48 states.
Upgrading your GR86's appearance is easier than ever with our diverse fitment options. Choose from sizes ranging up to 19 inches, including aggressive wider options that suit the performance character of your sports car. Whether you prefer the refined look of Heritage Wheel or the aggressive styling of KATANA RACING, Aodhan, F1R, and Vors, we've got the perfect setup waiting for you.
2022 Toyota GR86 Wheel Fitment Guide — What Works & What to Avoid
The 2022 Toyota GR86 uses a 5x100 bolt pattern across Base and Premium trims. Your stock setup runs 18x7.5 wheels at a 45mm offset. You can step down to 17-inch sizes or up to 19-inch, with widths ranging from 7.5 to 9.5 inches depending on diameter. This vehicle uses a square setup, so matching front and rear specifications keeps things simple.
Your GR86 demands the 5x100 bolt pattern—no other pattern will fit. The hub-centric bore sits at 56.1mm; if you choose wheels with a larger center bore, install hub-centric rings to ensure a proper fit. Aggressive width and offset combinations can risk contact with fenders or suspension components, so stay within the compatible size range we've verified.
Every wheel in our GR86 fitment catalog bolts on securely and ships free to the lower 48 states. Browse KATANA RACING, Work Wheels, Enkei, and others—all confirmed for your GR86 and ready to ship today.
2022 Toyota GR86 Wheel Fitment Specifications
The 5x100 bolt pattern determines which wheels physically bolt onto your car, while the 56.1mm center bore ensures a hub-centric fit. The factory equips this car with 18x7.5 wheels at a +45 offset.
Lug Type
nut
Thread Size
M12x1.25
Torque Spec
74 ft-lbs
TPMS
Yes
2022 Toyota GR86 Compatible Wheel Sizes
| Wheel Size | Offset Range | Compatible Tires | Notes |
|---|---|---|---|
| 18x7 | +35 to +48 | 225/40R18, 215/40R18 | — |
| 17x7.5 | +35 to +48 | 215/45R17 | 1. Check fitment, possible clearance issues |
| 18x7.5 | +35 to +48 | 225/40R18, 215/40R18 | — |
| 19x7.5 | +35 to +48 | 215/35R19 | — |
| 17x8 | +38 to +46 | 215/45R17, 235/40R17 | 1. Check fitment, possible clearance issues |
| 18x8 | +38 to +48 | 225/40R18, 235/35R18 | 1. Check fitment, possible clearance issues |
| 19x8 | +38 to +48 | 215/35R19 | 1. Check fitment, possible clearance issues |
| 18x8.5 | +38 to +45 | 225/40R18 | — |
Best Wheel Brands for the Toyota GR86
- Work Wheels — Meister, Emotion, Equip, CR Kiwami
- Volk Racing — TE37, CE28, ZE40
- SSR — Professor, Formula, GTX
- Gram Lights — 57CR, 57DR, 57Xtreme
- Enkei — RPF1, NT03, PF01
- Aodhan — DS02, AH02, AFF7
- WedsSport — SA-72R, TC105X
