2017 Ford Edge Wheels & Rims
Shop Wheels for 2017 Ford Edge
Showing 8 of 8+ wheels compatible with the 2017 Ford Edge
The 2017 Ford Edge SE, SEL, Sport, and Titanium models roll on a 5x108 bolt pattern with an 18x7.5 stock setup. ThreePiece.us offers a comprehensive range of sizes for your Edge, from 18-inch to 20-inch wheels that accommodate your vehicle's specifications. Every wheel we stock is verified to bolt on perfectly and ships free throughout the lower 48 states.
Your Edge can accept multiple wheel dimensions beyond stock, giving you flexibility in upgrading your look and performance. We carry premium brands including Heritage Wheel, Petrol, Asanti Black, fifteen52, Work Wheels, Niche 1PC, Motegi Racing, and Mazzi. Whether you're seeking aggressive stance options or refined elegance, our curated selection ensures you'll find the perfect fitment for your Ford.
2017 Ford Edge Wheel Fitment Guide — What Works & What to Avoid
Your 2017 Ford Edge requires five-lug, one-hundred-eight-millimeter bolt pattern wheels. The factory setup runs eighteen-by-seven-point-five inches at fifty-five offset. You can upgrade to nineteen or twenty-inch wheels in multiple widths, including eighteen-by-eight through eighteen-by-nine, or nineteen-by-seven-point-five up to nineteen-by-nine-point-five, plus twenty-by-ten-point-five—all bolt straight on without modification.
Since only five-by-one-oh-eight fitment works on this Edge, verify bolt pattern before purchasing. The hub centers at sixty-three-point-four millimeters; if your wheel's bore measures larger, hub-centric rings are required for a secure fit. Aggressive widths and aggressive offsets risk contact with fenders and suspension components, so stick within our verified fitment range to avoid clearance issues.
Every wheel we list for your Edge is confirmed to bolt on and ships free across the lower forty-eight states. We stock Heritage Wheel, Petrol, Asanti Black, fifteen52, Work Wheels, Niche 1PC, Motegi Racing, and Mazzi—all ready to ship.
2017 Ford Edge Wheel Fitment Specifications
The 5x108 bolt pattern determines which wheels physically bolt onto your truck, while the 63.4mm center bore ensures a hub-centric fit. The factory equips this truck with 18x7.5 wheels at a +55 offset.
Lug Type
nut
Thread Size
M14x1.5
Torque Spec
89 ft-lbs
TPMS
Yes
2017 Ford Edge Compatible Wheel Sizes
| Wheel Size | Offset Range | Compatible Tires | Notes |
|---|---|---|---|
| 21x10 | +45 to +45 | 285/35R21, 275/35R21, 265/40R21 | 22. TUV: Body Modification Required |
| 20x10.5 | +40 to +40 | 295/40R20, 285/40R20, 275/40R20 | 22. TUV: Body Modification Required |
| 18x7.5 | +35 to +55 | 235/60R18, 245/60R18 | — |
| 19x7.5 | +40 to +55 | 235/55R19, 245/55R19 | — |
| 18x8 | +35 to +55 | 235/60R18, 245/60R18 | — |
| 19x8 | +40 to +55 | 235/55R19, 245/55R19 | — |
| 20x8 | +40 to +55 | 255/45R20, 245/50R20 | — |
| 21x8 | +40 to +55 | 245/45R21, 255/40R21 | — |
| 18x8.5 | +40 to +55 | 235/60R18, 245/60R18 | — |
| 19x8.5 | +40 to +55 | 235/55R19, 245/55R19 | — |
| 20x8.5 | +40 to +55 | 255/45R20, 245/50R20 | — |
| 21x8.5 | +40 to +55 | 245/45R21, 255/40R21 | — |
| 18x9 | +40 to +40 | 285/50R18, 275/50R18, 255/55R18 | 22. TUV: Body Modification Required |
| 19x9 | +40 to +48 | 255/50R19 | — |
| 20x9 | +38 to +55 | 255/45R20 | — |
| 21x9 | +40 to +55 | 245/45R21, 255/40R21 | — |
| 22x9 | +40 to +45 | 265/35R22, 255/35R22, 245/35R22 | 21. TUV: Check fitment, possible clearance issues: 22. TUV: Body Modification Required |
| 19x9.5 | +40 to +40 | 285/45R19, 275/45R19 | 22. TUV: Body Modification Required |
| 20x9.5 | +40 to +50 | 255/45R20 | — |
| 21x9.5 | +40 to +50 | 265/40R21, 255/40R21 | — |
| 22x9.5 | +40 to +48 | 265/35R22 | — |
