2012 Fiat 500 Abarth Wheels & Rims
2012 Fiat 500 Abarth Wheel Gallery — See It On Your Car
Real Fiat 500 builds and AI-rendered fitment previews. Visualize any wheel on your 500 with our free wheel visualizer before you buy.
Shop Wheels for 2012 Fiat 500 Abarth
Showing 4 of 4+ wheels compatible with the 2012 Fiat 500
Finding the right wheels for your 2012 Fiat 500 Abarth is easier than ever. This agile Italian compact rolls on a 4x98 bolt pattern with a 58.1mm center bore, and the Abarth trim comes equipped with 16x6.5 wheels at a 35 offset from the factory. We stock premium options like Advan that fit perfectly, and every wheel is verified to bolt on before it ships free across the lower 48.
Whether you're seeking a subtle upgrade or a dramatic transformation, your Abarth has plenty of possibilities. You can explore sizes ranging from 16-inch through 18-inch diameters, with widths and offsets carefully selected to work with your car's specifications. All fitments are guaranteed compatible, so you can order with confidence and enjoy free shipping to your door.
2012 Fiat 500 Abarth Wheel Fitment Guide — What Works & What to Avoid
Your 2012 Fiat 500 Abarth bolts on a 4x98 pattern. The factory setup runs 16x6.5 wheels at 35 offset. You can step up to 17-inch or 18-inch fitments across multiple widths, including 17x7, 17x7.5, 18x7, 18x7.5, and 18x8, all without sacrificing square-setup balance for this non-staggered platform.
Since only 4x98 bolts to your Abarth, verify any wheel's pattern before purchase. Your hub requires a 58.1mm center bore; if your wheel's bore runs larger, use hub-centric rings to ensure a proper fit. Aggressive offsets or extreme widths risk contact with fenders and suspension components, so stay within our listed compatible sizes to avoid costly rubbing issues.
Every wheel we stock for your Abarth is confirmed to fit and ships free across the lower 48 states. Advan wheels are ready to ship now and transform your 500's appearance without compromise.
2012 Fiat 500 Abarth Wheel Fitment Specifications
The 4x98 bolt pattern determines which wheels physically bolt onto your car, while the 58.1mm center bore ensures a hub-centric fit. The factory equips this car with 16x6.5 wheels at a +35 offset.
Lug Type
bolt
Thread Size
M12x1.25
Torque Spec
70 ft-lbs
TPMS
Yes
2012 Fiat 500 Abarth Compatible Wheel Sizes
| Wheel Size | Offset Range | Compatible Tires | Notes |
|---|---|---|---|
| 16x6.5 | +25 to +38 | 195/45R16 | — |
| 17x6.5 | +25 to +38 | 195/40R17 | — |
| 16x7 | +25 to +38 | 195/45R16 | — |
| 17x7 | +25 to +38 | 205/40R17 | — |
| 18x7 | +25 to +35 | 215/35R18 | — |
| 16x7.5 | +35 to +38 | 225/40R16, 215/40R16, 215/35R16 | 21. TUV: Check fitment, possible clearance issues: 22. TUV: Body Modification Required |
| 17x7.5 | +25 to +35 | 205/40R17 | — |
| 18x7.5 | +30 to +32 | 215/35R18 | — |
| 18x8 | +30 to +32 | 215/35R18 | 1. Check fitment, possible clearance issues |
Best Wheel Brands for the Fiat 500
- BBS — LM, RS, FI, CI-R
- Volk Racing — TE37, ZE40
- Work Wheels — Meister, Emotion
- TSW — Bathurst, Nurburgring
- Rotiform — FLG, OZR, BUC
- Enkei — RPF1, TS-V
