2016 Scion FR-S Wheels & Rims
2016 Scion FR-S Wheel Gallery — See It On Your Car
Real Scion FR-S builds and AI-rendered fitment previews. Visualize any wheel on your FR-S with our free wheel visualizer before you buy.
Shop Wheels for 2016 Scion FR-S
Showing 8 of 8+ wheels compatible with the 2016 Scion FR-S
The 2016 Scion FR-S Base rolls on a 5x100 bolt pattern with stock 17x7 wheels. ThreePiece.us carries multiple wheel options perfectly suited to your FR-S, from aggressive 19-inch designs down to nimble 17-inch fitments. Every wheel we offer is verified to bolt on correctly, and we ship free throughout the lower 48 states.
Customization options abound for your FR-S thanks to a wide range of compatible sizes spanning 17 through 19 inches. Quality brands including Work Wheels, Enkei, Aodhan, and Motegi Racing are in stock, giving you choices across different styles and budgets. Get the exact look you want while enjoying our hassle-free fitment guarantee and complimentary shipping.
2016 Scion FR-S Wheel Fitment Guide — What Works & What to Avoid
The 2016 Scion FR-S bolts to a 5x100 pattern and rolls stock on 17x7 wheels at 48mm offset. You can upgrade to 17x6.5 or go wider to 17x7.5 and 17x8, then jump to 18-inch sizes including 18x7.5, 18x8, and 18x9.5, or select 19-inch options from 19x7 up to 19x8. Since this model runs a square setup, all fitment choices apply front and rear without stagger concerns.
Keep in mind only the 5x100 bolt pattern will fit your FR-S; no other patterns work on this car. The hub is 56.1mm bore, so if your wheel's center bore is larger, use hub-centric rings to ensure a proper fit. Aggressive offsets or very wide wheels risk rubbing against fenders and suspension components, so balance your size choice with sensible offset to maintain clearance.
Every wheel we list for your FR-S is confirmed to bolt on and qualifies for free shipping throughout the lower 48 states. We stock KATANA RACING, Enkei, Work Wheels, Aodhan, and F1R among our full selection, so you'll find quality options ready to ship.
2016 Scion FR-S Wheel Fitment Specifications
The 5x100 bolt pattern determines which wheels physically bolt onto your car, while the 56.1mm center bore ensures a hub-centric fit. The factory equips this car with 17x7 wheels at a +48 offset.
Lug Type
nut
Thread Size
M12x1.25
Torque Spec
74 ft-lbs
TPMS
Yes
2016 Scion FR-S Compatible Wheel Sizes
| Wheel Size | Offset Range | Compatible Tires | Notes |
|---|---|---|---|
| 17x6.5 | +35 to +48 | 215/45R17 | — |
| 17x7 | +35 to +48 | 215/45R17 | — |
| 19x7 | +35 to +48 | 215/35R19 | — |
| 17x7.5 | +35 to +48 | 215/45R17 | — |
| 18x7.5 | +35 to +48 | 225/40R18, 215/40R18 | — |
| 19x7.5 | +35 to +48 | 215/35R19 | — |
| 17x8 | +38 to +48 | 215/45R17, 235/40R17 | — |
| 18x8 | +38 to +48 | 225/40R18, 235/35R18 | — |
| 19x8 | +38 to +48 | 215/35R19 | — |
Best Wheel Brands for the Scion FR-S
- Work Wheels — Meister, Emotion, Equip, CR Kiwami
- Volk Racing — TE37, CE28, ZE40
- SSR — Professor, Formula, GTX
- Gram Lights — 57CR, 57DR, 57Xtreme
- Enkei — RPF1, NT03, PF01
- Aodhan — DS02, AH02, AFF7
- WedsSport — SA-72R, TC105X
