2018 Ram 1500 Wheels & Rims
2018 Ram 1500 Wheel Gallery — See It On Your Car
Real Ram 1500 builds and AI-rendered fitment previews. Visualize any wheel on your 1500 with our free wheel visualizer before you buy.
Shop Wheels for 2018 Ram 1500
Showing 8 of 8+ wheels compatible with the 2018 Ram 1500
Your 2018 Ram 1500 Big Horn, Express, HFE, Harvest, Laramie, Laramie Limited, Laramie Longhorn, Limited, Lone Star, Outdoorsman, Rebel, SLT, ST, SXT, Special Service, Sport, or Tradesman came standard with 17x7 wheels on a 5x139.7 bolt pattern. ThreePiece.us carries premium options from Carolina Forged, Icon Alloys, Vision, Black Rhino, American Racing, American Truxx, Fuel 1PC, and FULL THROTTLE that bolt right on without modification.
Every wheel we stock for your Ram is verified to fit and ships free to the lower 48 states. Choose from multiple 17-inch and 18-inch sizes—from 17x7 up to 18x10—to find the perfect setup that matches your style and performance needs.
2018 Ram 1500 Wheel Fitment Guide — What Works & What to Avoid
Your 2018 Ram 1500 uses a 5x139.7 bolt pattern with a 77.8mm hub-centric center bore. The stock wheel is 17x7 with a 25mm offset. You can upgrade to larger diameters like 18-inch wheels, or go wider within the 17-inch size—options range from 17x7 up to 17x9, plus several 18-inch widths from 7.5 to 9 inches. Since this truck runs square (not staggered), you have complete flexibility mixing and matching sizes front to rear.
Only wheels with a 5x139.7 bolt pattern will fit your Ram. If you select a wheel with a center bore larger than 77.8mm, use hub-centric rings to ensure proper fitment and balance. While this truck accommodates a wide range of sizes, be cautious with aggressive widths and offsets that push outward—extreme combinations risk rubbing on fenders or suspension components.
Every wheel we offer for your 2018 Ram 1500 is verified to bolt on and ships free throughout the lower 48 states. We stock quality brands including Carolina Forged, Icon Alloys, Vision, Black Rhino, American Racing, American Truxx, Fuel 1PC, and FULL THROTTLE—all ready to ship.
2018 Ram 1500 Wheel Fitment Specifications
The 5x139.7 bolt pattern determines which wheels physically bolt onto your truck, while the 77.8mm center bore ensures a hub-centric fit. The factory equips this truck with 17x7 wheels at a +25 offset.
Lug Type
nut
Thread Size
M14x1.5
Torque Spec
88 ft-lbs
TPMS
Yes
2018 Ram 1500 Compatible Wheel Sizes
| Wheel Size | Offset Range | Compatible Tires | Notes |
|---|---|---|---|
| 18x10 | -25 to +15 | 285/60R18, 305/60R18 | 5. Check tracking tolerance |
| 20x10 | -52 to -12 | 285/55R20, 295/55R20, 285/60R20 | 3. Extreme fitment/check lift kit requirements |
| 20x10 | -12 to +25 | 285/55R20, 295/55R20, 285/60R20 | — |
| 22x10 | -52 to -12 | 305/45R22, 285/45R22, 285/50R22 | 3. Extreme fitment/check lift kit requirements |
| 22x10 | -12 to +20 | 305/45R22, 285/45R22, 285/50R22 | — |
| 24x10 | -12 to +25 | 305/35R24, 295/35R24, 285/40R24 | — |
| 20x10.5 | -12 to +20 | 305/55R20, 305/50R20 | — |
| 22x10.5 | -12 to +20 | 305/45R22, 285/45R22, 325/40R22 | — |
| 24x10.5 | -12 to +20 | 305/35R24, 295/35R24, 315/35R24 | — |
| 20x11 | -12 to +15 | 305/55R20, 305/50R20 | — |
| 22x11 | -12 to +15 | 325/40R22, 305/45R22, 315/45R22 | — |
| 24x11 | -12 to +20 | 305/35R24, 295/35R24, 315/35R24 | — |
| 22x11.5 | -12 to +15 | 325/40R22, 305/45R22, 315/45R22 | — |
| 24x11.5 | -12 to +20 | 305/35R24, 295/35R24, 315/35R24 | — |
| 22x12 | -52 to -12 | 325/40R22, 315/45R22, 355/40R22 | 3. Extreme fitment/check lift kit requirements |
| 24x12 | -12 to +20 | 305/35R24, 315/35R24 | — |
| 17x7 | -12 to +25 | 265/70R17, 275/70R17, 255/75R17 | — |
| 17x7.5 | -12 to +25 | 265/75R17, 275/70R17, 285/70R17 | — |
| 18x7.5 | -12 to +25 | 265/65R18, 255/70R18, 275/65R18 | — |
| 17x8 | -12 to +25 | 265/70R17, 275/70R17, 285/70R17 | — |
| 18x8 | -12 to +25 | 285/60R18, 265/65R18, 255/70R18 | — |
| 20x8 | -12 to +25 | 275/60R20, 285/55R20, 265/60R20 | — |
| 17x8.5 | -12 to +25 | 265/70R17, 275/70R17, 285/70R17 | — |
| 18x8.5 | -12 to +25 | 285/60R18, 265/65R18, 255/70R18 | — |
| 20x8.5 | -12 to +25 | 275/60R20, 285/55R20, 265/60R20 | — |
| 17x9 | -12 to +25 | 265/70R17, 275/70R17, 285/70R17 | — |
| 18x9 | -12 to +25 | 285/60R18, 265/65R18, 275/65R18 | — |
| 20x9 | -15 to +25 | 285/60R20, 285/55R20, 295/55R20 | — |
| 22x9 | -12 to +25 | 285/45R22, 275/50R22, 285/50R22 | — |
| 18x9.5 | -12 to +25 | 285/60R18, 265/65R18, 275/65R18 | — |
| 20x9.5 | -12 to +25 | 285/60R20, 285/55R20, 295/55R20 | — |
| 22x9.5 | -12 to +25 | 285/45R22, 275/50R22, 285/50R22 | — |
Best Wheel Brands for the Ram 1500
- Fuel 1PC — Maverick, Assault, Blitz
- Fuel Forged — FF12, FF19
- Method Race Wheels — MR305, MR701
- American Racing — AR924, VN507
- Heritage Wheel
Complete Your 2018 Ram 1500 Build
- Ram 1500 suspension upgrades — pairs well with a wheel upgrade
- Ram 1500 exhaust systems — pairs well with a wheel upgrade
- Ram 1500 suspension — pairs well with a wheel upgrade
- Ram 1500 brakes — pairs well with a wheel upgrade
- Wheel & tire packages — pre-mounted, balanced, shipped ready to bolt on
- Installation accessories — hub rings, extended studs, TPMS kits, spacers
