1980 Mazda RX-7 Wheels & Rims
1980 Mazda RX-7 Wheel Gallery — See It On Your Car
Real Mazda RX-7 builds and AI-rendered fitment previews. Visualize any wheel on your RX-7 with our free wheel visualizer before you buy.
Shop Wheels for 1980 Mazda RX-7
Showing 8 of 8+ wheels compatible with the 1980 Mazda RX-7
The 1980 Mazda RX-7 GS and S models roll on a 4x110 bolt pattern with a 60.1mm center bore. Your stock setup uses 13x5 wheels at a 25mm offset. ThreePiece.us carries wheels specifically verified to fit your RX-7, with options from Vision, MSA Offroad Wheels, and Black Rhino Powersports ready to ship free to the lower 48 states.
Upgrading your classic RX-7 is straightforward when you choose from our compatible sizing range, which spans 13 to 15 inches in diameter. Whether you prefer the original 13x5 dimensions or want to step up to 15x6.5, every wheel we offer bolts directly onto your vehicle without modification. All fitments ship free throughout the continental United States.
1980 Mazda RX-7 Wheel Fitment Guide — What Works & What to Avoid
Your 1980 Mazda RX-7 GS or S uses a 4x110 bolt pattern with a 60.1mm hub-centric center bore. The stock wheel is 13x5 with a 25mm offset. You can fit larger sizes up to 15x6.5, including 13x5.5, 14x5.5, 14x6, 15x5.5, 15x6, and 15x6.5, all in the same square setup since this model runs non-staggered wheels.
Only 4x110 wheels will bolt to your RX-7—no other patterns work on this vehicle. The hub-centric bore is precisely 60.1mm, so use hub-centric rings if your wheel's center bore exceeds that size. Pushing too wide or too aggressive on offset risks rubbing the fender and suspension components, so stay within the tested size range.
Every wheel we list bolts on safely and ships free to the lower 48. Vision, MSA Offroad Wheels, and Black Rhino Powersports all carry fitments ready to ship for your RX-7.
1980 Mazda RX-7 Wheel Fitment Specifications
The 4x110 bolt pattern determines which wheels physically bolt onto your car, while the 60.1mm center bore ensures a hub-centric fit. The factory equips this car with 13x5 wheels at a +25 offset.
Lug Type
nut
Thread Size
M12x1.5
Torque Spec
81 ft-lbs
TPMS
No
1980 Mazda RX-7 Compatible Wheel Sizes
| Wheel Size | Offset Range | Compatible Tires | Notes |
|---|---|---|---|
| 13x5 | +20 to +25 | 165/80R13, 165HR13 | — |
| 13x5.5 | +20 to +25 | 165/80R13, 165HR13 | — |
| 14x5.5 | +20 to +25 | 185/70R14, 195/65R14 | — |
| 15x5.5 | +20 to +25 | 205/60R15 | — |
| 14x6 | +20 to +25 | 185/70R14, 195/65R14 | — |
| 15x6 | +20 to +25 | 205/60R15, 195/65R15 | — |
| 15x6.5 | +20 to +25 | 205/60R15, 195/65R15 | — |
Best Wheel Brands for the Mazda RX-7
- Work Wheels — Meister, Emotion, Equip, CR Kiwami
- Volk Racing — TE37, CE28, ZE40
- SSR — Professor, Formula, GTX
- Gram Lights — 57CR, 57DR, 57Xtreme
- Enkei — RPF1, NT03, PF01
- Aodhan — DS02, AH02, AFF7
- WedsSport — SA-72R, TC105X
