1963 Chevrolet Impala Wheels & Rims
1963 Chevrolet Impala Wheel Gallery — See It On Your Car
Real Chevrolet Impala builds and AI-rendered fitment previews. Visualize any wheel on your Impala with our free wheel visualizer before you buy.
Shop Wheels for 1963 Chevrolet Impala
Showing 8 of 8+ wheels compatible with the 1963 Chevrolet Impala
The 1963 Chevrolet Impala Base model originally rolled on fifteen-by-six wheels with a five-by-120.65 bolt pattern. ThreePiece.us carries a wide selection of authentic and modern designs from trusted manufacturers like American Racing, US Mag 1PC, and Performance Replicas, all verified to bolt directly onto your Impala.
Whether you're upgrading to a larger diameter or wider profile, your options range from fifteen-inch through sixteen-inch sizes in multiple widths. Every wheel we offer is guaranteed to fit your classic Impala and ships free to the lower 48 states, making it easy to transform your ride's appearance.
1963 Chevrolet Impala Wheel Fitment Guide — What Works & What to Avoid
Your 1963 Chevrolet Impala bolts to a 5x120.65 pattern. The stock wheel measures 15x6, and you can step up to larger sizes including 15x6.5, 15x7, 15x7.5, 15x8, 15x8.5, or move to 16-inch diameters up to 16x8.5. Since this is a square setup, front and rear use matching specs with no stagger considerations.
Only wheels with a 5x120.65 bolt pattern will fit your Impala—that's non-negotiable. The hub center bore measures 70.3mm, so verify that any wheel you choose either matches this bore or use hub-centric rings if the wheel's bore runs larger. Wider and more aggressive offsets can invite contact with fenders or suspension components, so choose conservatively if you're unsure.
Your fitment is confirmed to bolt on straight, and all wheels ship free within the lower 48 states. American Racing, US Mag 1PC, Performance Replicas, Vision, E5 Wheels, WELD Performance, Forgestar, and Ridler are among the brands we stock in your size range.
1963 Chevrolet Impala Wheel Fitment Specifications
The 5x120.65 bolt pattern determines which wheels physically bolt onto your vehicle, while the 70.3mm center bore ensures a hub-centric fit. The factory equips this vehicle with 15x6 wheels at a +null offset.
Lug Type
nut
Thread Size
7/16 UNF
Torque Spec
70 ft-lbs
TPMS
No
1963 Chevrolet Impala Compatible Wheel Sizes
| Wheel Size | Offset Range | Compatible Tires | Notes |
|---|---|---|---|
| 15x6 | -15 to +18 | 205/75R15 | — |
| 15x6.5 | -15 to +18 | 205/75R15 | — |
| 15x7 | -12 to +18 | 205/75R15, 215/65R15, 225/65R15 | — |
| 16x7 | -12 to +18 | 205/65R16, 215/60R16, 225/60R16 | — |
| 15x7.5 | -12 to +18 | 215/65R15, 225/65R15, 235/60R15 | — |
| 16x7.5 | -12 to +18 | 215/60R16, 225/60R16, 235/55R16 | — |
| 15x8 | -6 to +18 | 225/65R15, 235/60R15, 245/60R15 | — |
| 16x8 | -6 to +18 | 225/60R16, 235/55R16, 235/60R16 | — |
| 17x8 | -6 to +18 | 225/55R17, 235/50R17, 235/55R17 | — |
| 18x8 | -6 to +18 | 225/50R18, 235/45R18, 245/45R18 | — |
| 15x8.5 | -6 to +18 | 235/60R15, 245/60R15, 255/60R15 | — |
| 16x8.5 | -6 to +18 | 235/55R16, 235/60R16, 255/50R16 | — |
| 17x8.5 | -6 to +18 | 235/50R17, 235/55R17, 245/50R17 | — |
| 18x8.5 | -6 to +18 | 225/50R18, 235/45R18, 245/45R18 | — |
| 20x8.5 | -6 to +18 | 235/35R20, 245/35R20, 255/30R20 | — |
Best Wheel Brands for the Chevrolet Impala
Complete Your 1963 Chevrolet Impala Build
- Chevrolet Impala suspension — pairs well with a wheel upgrade
- Chevrolet Impala brakes — pairs well with a wheel upgrade
- Wheel & tire packages — pre-mounted, balanced, shipped ready to bolt on
- Installation accessories — hub rings, extended studs, TPMS kits, spacers
Ready to Upgrade Your 1963 Chevrolet Impala?
